FOR-X XMD-1716 NEO

Overall Dimensions: D*H 165mm*81mm Nominal Power Handling 150 W Transient Power 10ms 300 W Cone Material Paper Net Weight Kg 1.33kg DC Resistance Re 3.2 Ohms Voice Coil Diameter DIA 38.6mm Voice Coil Height 8 mm HE Magnetic Gap Height HE 8 mm Max Linear Excursion X Voice Coil Bobbin TIL Voice Coil Wire CCAW Number Of Layers 2 L Magnet System Type Neodymium BL Product BL 7,39 Suspension Compliance Cms 0.149 mm/N Mechanical Q Factor Qms 6 Electrical Q Factor Qes 0,43 Total Q Factor Qts 0,4 Moving Mass Mms 7.46 Gr Eq. Cas Air Load (liters) VAS 3.98 Lit Effective Piston Area SD 136.8cm^2 Die-Cast Aluminum Basket High Flux Neodymium Magnet System 1.5* Voice Coil Short Ring Inside
