12” subwoofer
600W RMS
1200W MAX
Impedance 4+4 OHM
Imp : 4 Ohm
Dcr : 1,7Ohm
Fs : 34.3 Hz
SD : 51.07 msqM
BL : 11,45 Tm
Qms : 4.083
Qes : 0. 576
Qts : 0,504
No : 0.294
SPLo : 86.7dB
Vas : 36,6 L
Cms : 98,81 uM/N
Mms : 194,47 g
Mmd : 187,84 g
Xmax : 13.0 ±
Vd 3.99

Features:
Heavy guage stamped basket;
Kevlar fiber reinforced non-press paper cone
Red stitched EROM foam surround;
2.5″ 4-layer round copper wire voice coil;
Reliable red poly-cotton 2-pc spiders;
Double stacked 120oz Strontium magnets;
Direct VC cooling motor design;
Push terminal;
Rubber magnet boot and rubber gasket;
DVC4-ohm Impedance;
600W RMS power and 1200W MAX power

*Above parameters are tested after each subwoofer was break-ined under 600W power for 8hours.
*Due to continuous pursuit of performance, specifications change without prior notice
